CL-600

  • CL-600

The belt conveyor is designed to transport the rock mass along the slab along the inclined inclination angle (from -3 degrees to +6 degrees).

During operation, the conveyor receives the transported material from the previous belt conveyor (or scraper drift conveyor), transports it along the slab, and then transfers the material to the next slat belt conveyor or main belt Conveyor.

Belt conveyors can be used as part of hydraulic machinery equipment.

Conveyor type

KL-600 , KL-600M

Conveying capacity, t / h

650

Belt speed, m/s

2.0 ... 3.15

Maximum conveyor length, m

1000

Belt width, mm

1000

Drive power, kW

2 × 75

Tilt angle, degree

-3 ... +6
