The passenger conveyor is designed to use one height to carry passengers, or to transport passengers from one height to another at a certain tilt angle.

In order to facilitate the entry and exit of passengers, the conveyor belt is equipped with an entrance platform. In order to avoid emergency situations, the conveyor design provides blocking devices, limit switches, and its tracking devices have been inserted into the circuit. Passenger conveyors are specially designed for heavy-duty and can be installed in subway stations, railway stations, airports, large exhibition centers and other places with heavy traffic. The railing of the passenger conveyor can be divided into two forms: glass windows and stainless steel guards (anti-vandalism).

Conveyor type

KPB-02M


Stroke, m

From 5 to 150


Roll paper speed (running speed) from the main drive, m/s:

-lowest

-Maximum



0.50

0.75

Drive power, kW

From 7.5 to 25

Load capacity, person/hour:

-Minimum operating speed

-At maximum operating speed



7040

8910

Blade floor width, mm

1003

Nominal web speed (repair speed), m/s

0.04

The sound level on the conveyor belt, dBA, no longer

70

Service life, years

fifty
